2025 Gas Hydrostatic 42-inch 25 HP V-Twin ELS Lawn Tractor

Quantity

ADD TO CART

BUY IT NOW

Detail

Powered by 20 HP (14.9 kW) Cyclonic engine
42-in. Accel Deep Mower Deck
Upgraded instrument panel
Best-in-class 4 year/300 hour limited warranty

Specifications

KEY SPECS

ENGINE POWER

22 HP 16.4 KW

OIL CHANGE

NO-TOOLS OIL DRAIN HOSE WITH REPLACEABLE FILTER

ENGINE MANUFACTURER/MODEL

44J6 CYCLONIC

TRANSAXLE TYPE

K46 HYDROSTATIC INTEGRATED WITH TRANSAXLE

TRANSAXLE CONTROL

TWIN TOUCH™ PEDALS

REAR TIRES

20×10-8

LIFT SYSTEM TYPE

FOOT PEDAL WITH OPTIONAL ADJUSTABLE SPRING ASSIST KIT

CUTTING WIDTH

ACCEL DEEP™ MOWER DECK. 42 IN. 107 CM

U.S. WARRANTY

4 YEAR/300 HOUR BUMPER-TO-BUMPER* (*TERM LIMITED TO YEARS OR HOURS USED. WHICHEVER COMES FIRST. AND VARIES BY MODEL. SEE THE LIMITED WARRANTY FOR NEW JOHN DEERE TURF AND UTILITY EQUIPMENT AT JOHNDEERE.COM OR JOHNDEERE.CA/TUWARRANTY FOR DETAILS.)

ENGINE

POWER

22 HP 16.4 KW

DISPLACEMENT

44.2 CU IN. 724 CC

MANUFACTURER/MODEL

44J6 CYCLONIC

TYPE

OVERHEAD VALVE. FULL-PRESSURE LUBE. OIL FILTER

CYLINDERS

V-TWIN. CAST-IRON LINERS

GOVERNOR

MECHANICAL

CHOKE/SPEED CONTROL

SEPARATE LEVERS. AUTOMATIC CHOKE RETURN

COOLING METHOD

AIR

AIR CLEANER

DRY. REPLACEABLE

OIL CHANGE

NO-TOOLS OIL DRAIN HOSE WITH REPLACEABLE FILTER

FUEL SYSTEM

TYPE

GASOLINE

FUEL DELIVERY

PULSE PUMP. CARBURETOR

FUEL GAUGE

GAUGE ON DASH

FUEL TANK LOCATION

REAR

FUEL FILL OPENING

ON LEFT FENDER. 3 IN. 7.6 CM

FUEL TANK CAPACITY

3.3 U.S. GAL. 12.5 L

ELECTRICAL SYSTEM

BATTERY

12 V 340 CCA

CHARGING SYSTEM

FLYWHEEL ALTERNATOR. REGULATED. 14 AMP

ENGINE STARTER

BENDIX

HOUR METER

YES

HEADLIGHTS

TWO STANDARD. INCANDESCENT. 27 W

TAILLIGHTS OR REFLECTOR

BACKUP LIGHTS

REAR WORK LIGHTS

12-V OUTLET

OPTIONAL

TRANSAXLE

TYPE

K46 HYDROSTATIC INTEGRATED WITH TRANSAXLE

CONTROL

TWIN TOUCH™ PEDALS

CRUISE CONTROL

YES. BUTTON ON DASH

OIL COOLER

FINS AND FAN ON TRANSAXLE

OIL FILTER

INTERNAL. NOT REPLACEABLE

DIFFERENTIAL LOCK

FORWARD SPEED

0-5.5 MPH 0-8.9 KM/H

REVERSE SPEED

0-4 MPH 0-6.4 KM/H

BRAKES

INTERNAL WET DISC

CHASSIS

FRAME

WELDED HEAVY-DUTY

PRIMER/PAINT

E-COAT/POWDER

WEIGHT BRACKET

STANDARD REAR. OPTIONAL FRONT

RECEIVER HITCH

FRONT AXLE

CAST IRON FRONT AXLE. FRONT WHEEL BALL BEARINGS

SPINDLE BUSHINGS

FRONT TIRES

15×6-6

REAR TIRES

20×10-8

HOOD MATERIAL

FULLY ENCLOSED. MOLDED-IN COLOR MATERIAL REDUCES SOUND. WILL NOT RUST OR DENT

FENDER DECK MATERIAL

STAMPED STEEL

FLOOR MATS

SURE-GRIP RUBBER

STORAGE

YES. UNDER SEAT AND COVERED TOOLBOX

SERVICE INTERVAL DECAL

YES

FENDER HANDLES/GRIPS

CUP HOLDER

YES

EQUIPMENT MOUNTING

YES. HEAVY DUTY

MAXIMUM TOWING CAPACITY

600 LB 272 KG

STEERING

TYPE

MANUAL. SECTOR AND PINION

FOUR-WHEEL STEER

NOT AVAILABLE ON THIS MODEL

STEERING WHEEL

LARGE. 14 IN. 35.6 CM

TILT STEERING WHEEL

TURNING RADIUS

16 IN. 40.6 CM

UNCUT CIRCLE RADIUS

26 IN. 66 CM

SEAT

TYPE

OPEN-BACK DESIGN WITH GRASP

SEAT BACK HEIGHT

15 IN. 38 CM

ARMRESTS

FORE-AFT ADJUSTMENT

WHILE SEATED. BALL BEARING SLIDE RAIL. 15-POSITION. 6.6 IN. 17 CM

SEAT SUSPENSION

TILT. TWO COIL SPRINGS. THREE-POSITION NO-TOOLS ADJUSTMENT FOR OPERATOR WEIGHT

LIFT SYSTEM

TYPE

FOOT PEDAL WITH OPTIONAL ADJUSTABLE SPRING ASSIST KIT

HYDRAULIC OUTLETS

MOWER CUT HEIGHT

13 POSITIONS. 1-4 IN. 2.5-10.2 CM

CUT HEIGHT INCREMENTS

0.25 IN. 0.64 CM

PRESET CUT HEIGHT

YES

MOWER DECK

TYPE

SIDE DISCHARGE

CUTTING WIDTH

ACCEL DEEP™ MOWER DECK. 42 IN. 107 CM

CONSTRUCTION

STAMPED STEEL DECK SHELL

MOWER DECK MATERIAL

12 GAUGE 0.105 IN. 2.7 MM

MOWER WASH PORT

YES

MOWER DRIVE SYSTEM

ELECTRIC POWER TAKE-OFF (PTO) CLUTCH. IN-LINE BELT

MOWER WHEELS

TWO

MOWER WHEEL ADJUSTMENT

FOUR-POSITION. TOOL REQUIRED

MOWER LEVEL ADJUSTMENT

EXACT ADJUST PORTS AND ONBOARD DECK-LEVELING GAUGE

MOWER ATTACHABILITY

TYPE

SLIDE UNDER TRACTOR

FRONT DRAFT ARMS

ATTACHED WITH SPRING PINS AT TWO POINTS

Customer Reviews

SEE ALL

Detail

Customer Reviews

Powered by 20 HP (14.9 kW) Cyclonic engine
42-in. Accel Deep Mower Deck
Upgraded instrument panel
Best-in-class 4 year/300 hour limited warranty

Specifications

KEY SPECS
ENGINE POWER	22 HP 16.4 KW
OIL CHANGE	NO-TOOLS OIL DRAIN HOSE WITH REPLACEABLE FILTER
ENGINE MANUFACTURER/MODEL	44J6 CYCLONIC
TRANSAXLE TYPE	K46 HYDROSTATIC INTEGRATED WITH TRANSAXLE
TRANSAXLE CONTROL	TWIN TOUCH™ PEDALS
REAR TIRES	20×10-8
LIFT SYSTEM TYPE	FOOT PEDAL WITH OPTIONAL ADJUSTABLE SPRING ASSIST KIT
CUTTING WIDTH	ACCEL DEEP™ MOWER DECK. 42 IN. 107 CM
U.S. WARRANTY	4 YEAR/300 HOUR BUMPER-TO-BUMPER* (*TERM LIMITED TO YEARS OR HOURS USED. WHICHEVER COMES FIRST. AND VARIES BY MODEL. SEE THE LIMITED WARRANTY FOR NEW JOHN DEERE TURF AND UTILITY EQUIPMENT AT JOHNDEERE.COM OR JOHNDEERE.CA/TUWARRANTY FOR DETAILS.)
ENGINE
POWER	22 HP 16.4 KW
DISPLACEMENT	44.2 CU IN. 724 CC
MANUFACTURER/MODEL	44J6 CYCLONIC
TYPE	OVERHEAD VALVE. FULL-PRESSURE LUBE. OIL FILTER
CYLINDERS	V-TWIN. CAST-IRON LINERS
GOVERNOR	MECHANICAL
CHOKE/SPEED CONTROL	SEPARATE LEVERS. AUTOMATIC CHOKE RETURN
COOLING METHOD	AIR
AIR CLEANER	DRY. REPLACEABLE
OIL CHANGE	NO-TOOLS OIL DRAIN HOSE WITH REPLACEABLE FILTER
FUEL SYSTEM
TYPE	GASOLINE
FUEL DELIVERY	PULSE PUMP. CARBURETOR
FUEL GAUGE	GAUGE ON DASH
FUEL TANK LOCATION	REAR
FUEL FILL OPENING	ON LEFT FENDER. 3 IN. 7.6 CM
FUEL TANK CAPACITY	3.3 U.S. GAL. 12.5 L
ELECTRICAL SYSTEM
BATTERY	12 V 340 CCA
CHARGING SYSTEM	FLYWHEEL ALTERNATOR. REGULATED. 14 AMP
ENGINE STARTER	BENDIX
HOUR METER	YES
HEADLIGHTS	TWO STANDARD. INCANDESCENT. 27 W
TAILLIGHTS OR REFLECTOR	NO
BACKUP LIGHTS	NO
REAR WORK LIGHTS	NO
12-V OUTLET	OPTIONAL
TRANSAXLE
TYPE	K46 HYDROSTATIC INTEGRATED WITH TRANSAXLE
CONTROL	TWIN TOUCH™ PEDALS
CRUISE CONTROL	YES. BUTTON ON DASH
OIL COOLER	FINS AND FAN ON TRANSAXLE
OIL FILTER	INTERNAL. NOT REPLACEABLE
DIFFERENTIAL LOCK	NO
FORWARD SPEED	0-5.5 MPH 0-8.9 KM/H
REVERSE SPEED	0-4 MPH 0-6.4 KM/H
BRAKES	INTERNAL WET DISC
CHASSIS
FRAME	WELDED HEAVY-DUTY
PRIMER/PAINT	E-COAT/POWDER
WEIGHT BRACKET	STANDARD REAR. OPTIONAL FRONT
RECEIVER HITCH	NO
FRONT AXLE	CAST IRON FRONT AXLE. FRONT WHEEL BALL BEARINGS
SPINDLE BUSHINGS	NO
FRONT TIRES	15×6-6
REAR TIRES	20×10-8
HOOD MATERIAL	FULLY ENCLOSED. MOLDED-IN COLOR MATERIAL REDUCES SOUND. WILL NOT RUST OR DENT
FENDER DECK MATERIAL	STAMPED STEEL
FLOOR MATS	SURE-GRIP RUBBER
STORAGE	YES. UNDER SEAT AND COVERED TOOLBOX
SERVICE INTERVAL DECAL	YES
FENDER HANDLES/GRIPS	NO
CUP HOLDER	YES
EQUIPMENT MOUNTING	YES. HEAVY DUTY
MAXIMUM TOWING CAPACITY	600 LB 272 KG
STEERING
TYPE	MANUAL. SECTOR AND PINION
FOUR-WHEEL STEER	NOT AVAILABLE ON THIS MODEL
STEERING WHEEL	LARGE. 14 IN. 35.6 CM
TILT STEERING WHEEL	NO
TURNING RADIUS	16 IN. 40.6 CM
UNCUT CIRCLE RADIUS	26 IN. 66 CM
SEAT
TYPE	OPEN-BACK DESIGN WITH GRASP
SEAT BACK HEIGHT	15 IN. 38 CM
ARMRESTS	NO
FORE-AFT ADJUSTMENT	WHILE SEATED. BALL BEARING SLIDE RAIL. 15-POSITION. 6.6 IN. 17 CM
SEAT SUSPENSION	TILT. TWO COIL SPRINGS. THREE-POSITION NO-TOOLS ADJUSTMENT FOR OPERATOR WEIGHT
LIFT SYSTEM
TYPE	FOOT PEDAL WITH OPTIONAL ADJUSTABLE SPRING ASSIST KIT
HYDRAULIC OUTLETS	NO
MOWER CUT HEIGHT	13 POSITIONS. 1-4 IN. 2.5-10.2 CM
CUT HEIGHT INCREMENTS	0.25 IN. 0.64 CM
PRESET CUT HEIGHT	YES
MOWER DECK
TYPE	SIDE DISCHARGE
CUTTING WIDTH	ACCEL DEEP™ MOWER DECK. 42 IN. 107 CM
CONSTRUCTION	STAMPED STEEL DECK SHELL
MOWER DECK MATERIAL	12 GAUGE 0.105 IN. 2.7 MM
MOWER WASH PORT	YES
MOWER DRIVE SYSTEM	ELECTRIC POWER TAKE-OFF (PTO) CLUTCH. IN-LINE BELT
MOWER WHEELS	TWO
MOWER WHEEL ADJUSTMENT	FOUR-POSITION. TOOL REQUIRED
MOWER LEVEL ADJUSTMENT	EXACT ADJUST PORTS AND ONBOARD DECK-LEVELING GAUGE
MOWER ATTACHABILITY
TYPE	SLIDE UNDER TRACTOR
FRONT DRAFT ARMS	ATTACHED WITH SPRING PINS AT TWO POINTS
